This Identification Guide for Lionel Electric Trains covers the "Post-war Era" only from 1945 until 1969.

black horizontal bar

Lionel Trains Type R Transformer LIONEL TRAINS TRANSFORMER TYPE R

black horizontal bar

Lionel Trains Transformer Type R Variation B
spacer
Type R Box End
spacer

Lionel Trains Type R TransformerThe Lionel Type R Transformer was available in 1946 and 1947. It produced 110 Watts on two independent circuits each producing 6-24 Volts. This transformer did not have a built-in whistle or directional control and is used in conjunction with the No. 167 Whistle Controller that added these features. There are two variations:
spacer
Variation A: Shows power output as 100 Watts. 1946 Production.
spacer
Variation B: Shows power output as 110 Watts, it came with an instruction sheet that was dated 6-47. 1947 Production.

Type R Terminals
spacer
Type R Instruction Sheet Page 1
